5–58 Maintenance and Service Guide
Removal and Replacement Procedures
5.18 USB/Audio Board
1. Prepare the computer for disassembly (Section 5.3),
and then remove the following components:
a. Hard drive (Section 5.4)
b. Optical drive (Section 5.9)
c. Switch cover (Section 5.10)
d. Keyboard assembly (Section 5.11)
e. Display assembly (Section 5.14)
f. Top cover (Section 5.15)
g. System board (Section 5.17)
USB/Audio Board Spare Part Number Information
✎
USB/audio boards include USB/audio board cable.
For use with full-featured models
For use with defeatured models
407802-001
407803-001
