Removal and Replacement Procedures
Maintenance and Service Guide 5–11
5.6 Memory Module
1. Prepare the computer for disassembly (refer to Section 5.3).
2. Loosen the two black Phillips PM2.5×5.0 screws 1 that
secure the memory/Mini PCI module compartment cover to
the computer.
3. Lift the right side of the cover 2 and swing it up and to the
left and remove it.
✎
The memory/Mini PCI module compartment cover is included
in the Plastics Kit, spare part number 407778-001.
Removing the Memory/Mini PCI Module Compartment Cover
Memory Module Spare Part Number Information
1024 MB
512 MB
256 MB
403800-001
403799-001
407843-001
