5ā12 Maintenance and Service Guide
Removal and Replacement Procedures
4. Loosen the two Phillips PM2.5Ć3.0 screws 1 that secure
the memory module shield to the computer.
5. Lift the left side of the shield 2 and swing it to the right
until it is resting in an upright position.
ā
The memory shield is included in the Bracket Kit, spare part
number 407820-001.
Releasing the Memory Module Shield
