5–48 Maintenance and Service Guide
Removal and Replacement Procedures
5.16 Bluetooth Module
1. Prepare the computer for disassembly (Section 5.3),
and then remove the following components:
a. Hard drive (Section 5.4)
b. Memory/Mini PCI module compartment cover
(Section 5.6)
c. Optical drive (Section 5.9)
d. Switch cover (Section 5.10)
e. Keyboard assembly (Section 5.11)
f. Display assembly (Section 5.14)
g. Top cover (Section 5.15)
Bluetooth Module Spare Part Number Information
Bluetooth module (includes Bluetooth module cable) 397922-001
