HP Pavilion DV5000 Maintenance And Service Guide

5–50 Maintenance and Service Guide
Removal and Replacement Procedures
5.17 System Board
✎
When replacing the system board, ensure that the following
components are removed from the defective system board and
installed on the replacement system board:
■ Memory modules (Section 5.6)
■ Mini PCI communications module (Section 5.7)
■ RTC battery (Section 5.8)
■ Power connector and cable (Section 5.17)
■ Heat sink (Section 5.19)
■ Processor (Section 5.20)
■ Fan assembly (Section 5.21)
■ Fan assembly (Section 5.22)
■ PC Card assembly (Section 5.23)
1. Prepare the computer for disassembly (Section 5.3),
and then remove the following components:
a. Hard drive (Section 5.4)
b. Optical drive (Section 5.9)
c. Switch cover (Section 5.10)
d. Keyboard assembly (Section 5.11)
e. Display assembly (Section 5.14)
f. Top cover (Section 5.15)
g. Bluetooth module(Section 5.16)
System Board Spare Part Number Information
For use with full-featured models
For use with defeatured models
407830-001
407831-001
Download from Www.Somanuals.com. All Manuals Search And Download.

HP Pavilion DV5000 Specifications

General

CPU	Intel Pentium M or Intel Celeron M
Chipset	Intel 915GM
Memory	Up to 2 GB DDR2
Graphics	Intel Graphics Media Accelerator 900
Display	15.4-inch WXGA
Hard Drive	40 GB to 100 GB
Optical Drive	DVD\u00b1RW
Wireless	802.11b/g
Operating System	Windows XP Home or Windows XP Professional
Battery Life	Up to 3 hours
Ports	3 USB 2.0, VGA, S-Video, Ethernet, Modem, Headphone, Microphone, ExpressCard/54
