Specifications
Maintenance and Service Guide 6–3
Table 6-2
15.4-inch, WXGA, Display
Dimensions
Height
Width
Diagonal
20.7 cm
33.1 cm
39.1 cm
8.15 in
13.03 in
15.39 in
Number of colors Up to 16.8 million
Contrast ratio 200:1
Brightness 180 nits typical
Pixel resolution
Pitch
Format
Configuration
0.259 × 0.259 mm
1280 × 800
RGB vertical stripe
Backlight Edge lit
Character display 80 × 25
Total power consumption 4 W
Viewing angle +/-65° horizontal, +50° vertical typical
