Screw Listing
Maintenance and Service Guide C–13
Phillips PM2.5×11.0 Screw Locations
Table C-5
Phillips PM2.5×11.0 Screw
Color Qty. Length Thread
Head
Width
Black 20 11.0 mm 2.5 mm 6.0 mm
Where used:
1 One screw that secures the optical drive to the computer (documented in
Section 5.9)
2 Two screws that secure the switch cover to the computer (documented in
Section 5.10)
mm
