Screw Listing
Maintenance and Service Guide C–31
Slotted SM1.5×9.0 Screw Locations
Table C-11
Slotted SM1.5×9.0 Screw
Color Qty. Length Thread
Head
Width
Silver 2 9.0 mm 1.5 mm 2.0 mm
Where used:
2 screws that secure the expansion port 2 bracket and fan assembly to
the system board (documented in Section 5.21)
mm
