HP Pavilion DV5000 Maintenance And Service Guide

Contents
Maintenance and Service Guide v
5 Removal and Replacement Procedures
5.1 Serial Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–1
5.2 Disassembly Sequence Chart . . . . . . . . . . . . . . . . . . 5–2
5.3 Preparing the Computer for Disassembly . . . . . . . . . 5–4
5.4 Hard Drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–6
5.5 Computer Feet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–10
5.6 Memory Module . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–11
5.7 Mini PCI Communications Module . . . . . . . . . . . . 5–14
5.8 RTC Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–16
5.9 Optical Drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–17
5.10 Switch Cover. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–19
5.11 Keyboard Frame . . . . . . . . . . . . . . . . . . . . . . . . . . 5–21
5.12 LED Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–25
5.13 Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–27
5.14 Display Assembly . . . . . . . . . . . . . . . . . . . . . . . . . 5–29
5.15 Top Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–40
5.16 Bluetooth Module . . . . . . . . . . . . . . . . . . . . . . . . . 5–48
5.17 System Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–50
5.18 USB/Audio Board . . . . . . . . . . . . . . . . . . . . . . . . . 5–58
5.19 Heat Sink. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–60
5.20 Processor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–63
5.21 Fan Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–66
5.22 Speakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–69
5.23 PC Card Assembly . . . . . . . . . . . . . . . . . . . . . . . . 5–71
5.24 ExpressCard Assembly . . . . . . . . . . . . . . . . . . . . . 5–74
Download from Www.Somanuals.com. All Manuals Search And Download.

HP Pavilion DV5000 Specifications

General

CPU	Intel Pentium M or Intel Celeron M
Chipset	Intel 915GM
Memory	Up to 2 GB DDR2
Graphics	Intel Graphics Media Accelerator 900
Display	15.4-inch WXGA
Hard Drive	40 GB to 100 GB
Optical Drive	DVD\u00b1RW
Wireless	802.11b/g
Operating System	Windows XP Home or Windows XP Professional
Battery Life	Up to 3 hours
Ports	3 USB 2.0, VGA, S-Video, Ethernet, Modem, Headphone, Microphone, ExpressCard/54
