3–10 Maintenance and Service Guide
Illustrated parts catalog
Mass storage devices
Item Description Spare part number
1
Hard drive (includes left and right bracket rails, connector cable, Mylar cover with tab, and 4 rubber isolators):
■ 500-GB, 7200-rpm 575402-001
■ 500-GB, 5400-rpm 511879-001
■ 320-GB, 7200-rpm 511876-001
■ 320-GB, 5400-rpm 511877-001
■ 250-GB, 7200-rpm 511874-001
■ 250-GB, 5400-rpm 511875-001
Hard Drive Hardware Kit (not illustrated, includes left and right bracket rails,
connector cable, Mylar cover with tab, and 4 rubber isolators)
483862-001
2
Optical drive (includes bezel and bracket)
■ DVD±RW and CD-RW SuperMulti Double-Layer Combo Drive with LightScribe 511880-001
■ Blu-ray ROM with LightScribe DVD±R/RW SuperMulti Double-Layer Drive 511882-001
