4–32 Maintenance and Service Guide
Removal and replacement procedures
8. Lift the rear edge 1 of the top cover until it rests at an angle.
9. Remove the top cover 2 by lifting it straight up.
Reverse this procedure to install the top cover.
Bluetooth module
✎
The Bluetooth module spare part kit does not include a Bluetooth module cable. The Bluetooth module cable is
available using spare part number 579161-001.
Before removing the Bluetooth module, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on,
and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the battery (see “Battery” on page 4-6).
5. Remove the switch cover and keyboard (see “Switch cover and keyboard” on page 4-18).
Description Spare part number
Bluetooth module 537921-001
