Removal and replacement procedures
Maintenance and Service Guide 4–19
4. Remove the battery (see “Battery” on page 4-6).
Remove the switch cover and keyboard:
1. Turn the computer upside down, with the front toward you.
2. Remove the following screws:
a. Two Phillips PM2.5×7.0 screws 1 that secure the switch cover to the computer
b. Three Phillips PM2.5×4.0 screws 2 that secure the switch cover to the computer (these are inside the
battery bay)
c. Three Phillips PM2.5×6.5 screws 3 that secure the keyboard to the computer
3. Turn the computer display-side up, with the front toward you, and open the computer as far as possible.
4. Lift the rear edge of the switch cover until it detaches from the computer.
