Switch cover
Description Spare part number
Switch cover (includes LED board and cable) 446512-001
Before removing the switch cover, follow these steps:
1.
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2.
Disconnect all external devices connected to the computer.
3.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4.
Remove the battery (see
Battery on page 46).
Remove the switch cover:
1.
Remove the three Phillips PM2.5×5.0 screws that secure the switch cover to the computer.
2.
Turn the computer display-side up, with the front toward you.
3.
Open the computer as far as possible.
Component replacement procedures 61
