Display assembly
Description Spare part number
15.4-inch, WXGA, BrightView, display assembly for use only with computer models equipped with a
camera (includes camera, microphones, and WLAN transceivers and antenna cables)
446481-001
15.4-inch, WXGA, BrightView, display assembly for use only with computer models not equipped
with a camera (includes microphones and WLAN transceivers and antenna cables)
446482-001
15.4-inch, WXGA, BrightView, display assembly for use only with Best Buy computer models equipped
with a camera, microphones, and a fingerprint reader (includes camera, microphones, and WLAN
transceivers and antenna cables)
455311–001
15.4-inch, WXGA, BrightView, display assembly for use only with Best Buy computer models equipped
with a camera (includes camera, microphones, and WLAN transceivers and antenna cables)
455312-001
Before removing the display assembly, follow these steps:
1.
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2.
Disconnect all external devices connected to the computer.
3.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4.
Remove the battery (see
Battery on page 46).
5.
Remove the memory/WLAN module compartment cover (see
Memory module on page 53).
6.
Disconnect the wireless antenna cables from the WLAN module (see
WLAN module on page 56).
7.
Remove the following components:
a.
Keyboard (see
Keyboard on page 65)
b.
Switch cover (see
Switch cover on page 61)
c.
Speaker assembly (see
Speaker assembly on page 63)
Remove the display assembly:
1.
Close the computer and turn it upside down, with the rear panel toward you.
68 Chapter 4 Removal and replacement procedures
