Audio board

Description Spare part number

Audio board (includes audio connectors, audio board cable, and infrared lens) 446523-001

Before removing the audio board, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

Battery on page 41).

5. Remove the following components:

Hard drive (see

Hard drive on page 46)

Optical drive (see

Optical drive on page 54)

Switch cover (see

Switch cover on page 56)

d. Keyboard (see

Keyboard on page 60)

e. Speaker assembly (see

Speaker assembly on page 58)

Display assembly (see

Display assembly on page 63)

g. Top cover (see

Top cover on page 69)

h. System board (see

System board on page 77)

Remove the audio board:

1. Remove the two Phillips PM2.5×4.0 screws (1) that secure the audio board to the computer.

2. Release the audio board (2) by sliding it back to disengage the audio connectors from the openings

in the base enclosure.

80 Chapter 4 Removal and replacement procedures
