HP Pavilion dv8000 - LED Board

Removal and Replacement Procedures
Maintenance and Service Guide 5–27
5.12 LED Board
1. Prepare the computer for disassembly (Section 5.3) and then
remove the following components:
a. Memory/Mini PCI module compartment cover
(Section 5.6)
b. Switch cover (Section 5.10)
c. Keyboard assembly frame (Section 5.11)
2. Turn the keyboard assembly frame upside down with the
LED board toward you.
LED Board Spare Part Number Information
For use with HP Pavilion dv8200 models
For use with HP Pavilion dv8000 models
417033-001
403833-001
