5–60 Maintenance and Service Guide
Removal and Replacement Procedures
5.18 Modem Connector Cable
✎
The modem connector cable is included in the Cable Kit, spare
part number 403814-001.
1. Prepare the computer for disassembly (Section 5.3),
and then remove the following components:
a. Hard drive (Section 5.4)
b. Memory/Mini PCI module compartment cover
(Section 5.6)
c. Optical drive (Section 5.9)
d. Switch cover (Section 5.10)
e. Keyboard assembly frame (Section 5.11)
f. Display assembly (Section 5.14)
g. Top cover (Section 5.15)
To Next Page
