Removal and Replacement Procedures
Maintenance and Service Guide 5–59
5. Slide and hold the battery release latch acuator 1 to the right.
6. Slide the Bluetooth module cable 2 through the hole in the
battery release latch actuator 3 and the clips in the base
enclosure.
7. Remove the Bluetooth module cable 4 from the clip in
the base enclosure.
✎
The Bluetooth module cable is included with the Bluetooth
module and is also available in the Cable Kit, spare part
number 403814-001.
Removing the Bluetooth Module Cable
Reverse the above procedure to install the Bluetooth module.
