1–22 Maintenance and Service Guide
Product Description
The external components on the bottom of the computer are
shown below and described in Table 1-9.
Bottom Components
Table 1-9
Bottom Components
Item Component Function
1 Optical drive Supports an optical disc, such as a
CD or DVD.
2 Labels area Contains the serial number and other
information labels.
3 Battery release latch Releases a battery from the battery bay.
4 Battery bay Holds a battery.
