Table 3-1 Computer major components and their descriptions (continued)
Item Component Spare part number
(7) Speakers (include left and right speakers and cable) L51127-001
(8) System board (includes processor)
NOTE: All system board spare part kits include replacement thermal material.
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating systems
xxxxxx-601: Windows operating system
For use in models with discrete graphics memory:
● Intel Core i7-8565U processor and 2 GB GeForce MX250 graphics memory L51138-xx1
● Intel Core i5-8265U processor and 2 GB GeForce MX130 graphics memory L51137-xx1
● Intel Core i3-8145U processor and 2 GB GeForce MX130 graphics memory L51136-xx1
For use in models with UMA graphics memory:
● Intel Core i7-8565U processor L51134-xx1
● Intel Core i5-8265U processor L51133-xx1
● Intel Core i3-8145U processor L51132-xx1
● Pentium N5000 processor L51135-xx1
Thermal pad, for use in models with discrete graphics memory (not illustrated) L21302-001
(9) Power connector cable L51098-001
(10) Fingerprint reader
Ash silver L51113-001
Natural silver L51840-001
Luminous gold L51841-001
(11) Heat sink (includes replacement thermal material)
For use in models with an Intel Core processor and with discrete graphics.
L51101-001
(12) Heat sink (includes replacement thermal material)
For use in models with a fan with an Intel Core processor and with UMA graphics
L51100-001
Heat sink (includes replacement thermal material) (not illustrated)
For use in fanless models with an Intel Pentium processor and with UMA graphics (not
illustrated)
L51099-001
(13) Fan L51102-001
(14) Memory cover L51104-001
(15) Memory module (DDR4)
8 GB 937236-855
4 GB L10598-855
(16) WLAN module
Computer major components 17
