Memory
Description Spare part number
4-GB, PC3-10600 585157-001
2-GB, PC3-10600 635803-001
1-GB, PC3-10600 635802-001
The computer comes with double data rate 3 synchronous dynamic random access memory (DDR3-
SDRAM) dual inline memory modules (DIMMs).
DDR3-SDRAM DIMMs
There are two DIMM slots on the system board.
These memory sockets are populated with at least one preinstalled DIMM. To achieve the maximum
memory support, you can populate the system board with up to 8 GB of memory.
Figure 7-5 DIMM Socket Locations
Table 7-1 DIMM Socket Locations
Description Socket Color Insertion Order
XMM1 socket, Channel A (populate first) Black 1
XMM3 socket, Channel B Black 2
NOTE: A DIMM must occupy the XMM1 socket.
Memory 47
