Expansion Card
Description Spare part number
ATI Radeon HD 6350 512-MB graphics adapter 637995-001
ATI Radeon HD 6450 512-MB graphics adapter 637996-001
ATI Radeon HD 6450 1-GB graphics adapter, PCIe x16 666330-001
nVidia Quadro NVS300 PCIe x16 graphics card, 512 MB, PCIe x16 632486-001
nVidia Quadro NVS300 PCIe x16 graphics card, 512 MB, PCIe x1 632827-001
nVidia GeForce GT405 512-MB graphics adapter 657108-001
Intel Gigabit NIC, includes bracket 490367-001
The computer has one PCI Express x1 expansion slot, one PCI Express x16 expansion slot, and two
PCI expansion slots. The expansion slots accommodate full-height or half-height expansion cards.
Figure 8-9 Expansion Slot Locations
Table 8-2 Expansion Slot Locations
Item Description
PCIE X16 PCI Express x1 expansion slot
PCIEX1_1 PCI Express x16 expansion slot
PCI1 PCI slot
PCI2 PCI slot
98 Chapter 8 Removal and Replacement Procedures – Small Form Factor (SFF) Chassis
