Drive Positions
Figure 7-15 Drive Positions
1 Two 5.25-inch external drive bays for optical drives
2 One 3.5-inch external drive bay for media card reader
3 Two 3.5-inch internal hard drive bays
To verify the type, size, and capacity of the storage devices installed in the computer, run Computer
Setup. Refer to
Computer Setup (F10) Utility on page 7 for more information.
60 Chapter 7 Removal and Replacement Procedures – Microtower (MT) Chassis
