6. Remove the 7 Torx T8M2.5×6.0 screws from the top of the computer.
7. Disconnect the following cables from the system board:
●
(1): Power button board cable
●
(2): Speaker cable
●
(3): Function board cable
●
(4): Card reader cable
8. Pry the top cover off the computer to disengage it.
NOTE: Begin by attempting to pry the top cover loose near the optical drive.
Component replacement procedures 55
