HP ProBook 4525s Service Manual

6 Computer Setup
Computer Setup
Starting Computer Setup
Computer Setup is a preinstalled, ROM-based utility that can be used even when the operating
system is not working or will not load.
NOTE: Some of the Computer Setup menu items listed in this guide may not be supported by your
computer or your operating system.
NOTE: An external keyboard or mouse connected to a USB port can be used with Computer Setup
only if USB legacy support is enabled.
To start Computer Setup, follow these steps:
1. Turn on or restart the computer, and then press esc while the “Press the ESC key for Startup
Menu” message is displayed at the bottom of the screen.
2. Press f10 to enter BIOS Setup.
Using Computer Setup
Navigating and selecting in Computer Setup
The information and settings in Computer Setup are accessed from the File, Security, and System
Configuration menus.
To navigate and select in Computer Setup, follow these steps:
1. Turn on or restart the computer, and then press esc while the “Press the ESC key for Startup
Menu” message is displayed at the bottom of the screen.
●
To select a menu or a menu item, use the tab key and the keyboard arrow keys and then
press enter, or use a pointing device to click the item.
●
To scroll up and down, click the up arrow or the down arrow in the upper-right corner of the
screen, or use the up arrow key or the down arrow key.
●
To close open dialog boxes and return to the main Computer Setup screen, press esc, and
then follow the on-screen instructions.
106 Chapter 6 Computer Setup

HP ProBook 4525s Specifications

General

Graphics	ATI Mobility Radeon HD 4250
Processor	AMD Turion II, AMD Athlon II
Display	15.6-inch diagonal LED-backlit HD anti-glare (1366 x 768 resolution)
Memory	Up to 8 GB DDR3
Storage	250GB, 320GB, 500GB HDD
Operating System	Genuine Windows 7 Professional, Genuine Windows 7 Home Premium, Genuine Windows 7 Home Basic
Battery	6-cell Lithium-Ion
Chipset	AMD M880G
Optical Drive	DVD+/-RW SuperMulti DL
Wireless	802.11b/g/n, Bluetooth 2.1
Audio	Integrated stereo speakers, Integrated microphone
Ports	3 USB 2.0, VGA, HDMI, RJ-45, headphone/microphone combo jack
Card Reader	SD/MMC
Webcam	2 MP Webcam
