3. Lift the heat sink from the system board (7).
NOTE: Thoroughly clean thermal material from the surfaces of the system board components (1)(3)
and the heat sink (2)(4) each time you remove the heat sink. All heat sink and processor spare part kits
include thermal material.
Reverse this procedure to install the heat sink assembly.
74 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
