Heat sink assembly
All heat sink assembly spare part kits include replacement thermal material.
Description Spare part number
Heat sink for use in models with discrete graphics 828396-001
Before removing the heat sink assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and
then unplugging the AC adapter from the computer.
4. Remove the battery (see Battery on page 31).
5. Remove the following components:
a. Service doors (see Service doors on page 32).
b. Hard drive (see Hard drive on page 36)
c. Optical drive (Optical drive on page 34)
d. WLAN module (see WLAN/Bluetooth combo card on page 40)
e. Keyboard (see Keyboard on page 43)
f. Top cover (see Top cover on page 48)
g. System board (see System board on page 66)
Remove the heat sink assembly:
1. Position the system board upside-down.
2. In the order indicated on the heat sink, loosen the 6 captive Phillips screws (1)–(6) that secure the heat
sink to the system board.
Component replacement procedures 73
