HP ProCurve Switch 1400 Series
Specifications
HP ProCurve Switch 1400-24G (J9078A) HP ProCurve Switch 1400-8G (J9077A)
Ports
22 auto-sensing 10/100/1000 ports (IEEE 802.3 Type 10Base-T, IEEE 802.3u
Type 100Base-TX, IEEE 802.3ab Type 1000Base-T); Media Type: Auto-MDIX;
Duplex: 10Base-T/100Base-TX: half or full; 1000Base-T: full only
2 dual-personality ports; each port can be used as either an RJ-45
10/100/1000 port (IEEE 802.3 Type 10Base-T; IEEE 802.3u Type
100Base-TX; IEEE 802.3ab 1000Base-T Gigabit Ethernet) or an open mini-GBIC
slot (for use with mini-GBIC transceivers)
8 auto-sensing 10/100/1000 ports (IEEE 802.3 Type 10Base-T, IEEE 802.3u
Type 100Base-TX, IEEE 802.3ab Type 1000Base-T); Media Type: Auto-MDIX;
Duplex: 10Base-T/100Base-TX: half or full; 1000Base-T: full only
Physical characteristics
Dimensions
6.74(d) x 17.42(w) x 1.73(h) in. (17.12 x 44.25 x 4.39 cm) (1U height) 4.58(d) x 7.73(w) x 1.73(h) in. (11.63 x 19.63 x 4.39 cm) (1U height)
Weight
4.38 lb. (1.99 kg) 1.19 lb. (0.54 kg)
Memory and processor
128 KB RAM/ROM capacity; packet buffer size: 500 KB 128 KB RAM/ROM capacity; packet buffer size: 144 KB
Mounting
Mounts in an EIA-standard 19 in. telco racks (hardware included) Horizontal surface mounting only
Performance
100 Mb Latency
< 4.7 µs (64-byte packets) < 3.9 µs (64-byte packets)
1000 Mb Latency
< 3.0 µs (64-byte packets) < 2.1 µs (64-byte packets)
Throughput
up to 35.7 million pps up to 11.9 million pps
Switching capacity
48 Gbps 16 Gbps
MAC address table size
8,000 entries 8,000 entries
Environment
Operating temperature
32ºF to 104ºF (0ºC to 40ºC) 32ºF to 104ºF (0ºC to 40ºC)
Operating relative humidity
15% to 95% @ 104ºF (40ºC), non-condensing 15% to 95% @ 104ºF (40ºC), non-condensing
Non-operating/Storage temperature
-40ºF to 158ºF (-40ºC to 70ºC) -40ºF to 158ºF (-40ºC to 70ºC)
Non-operating/Storage relative humidity
10% to 90% @ 149ºF (65ºC), non-condensing 10% to 90% @ 149ºF (65ºC), non-condensing
Altitude
up to 10,000 ft. (3 km) up to 10,000 ft. (3 km)
Acoustic
Power: 0 dB No Fan Power: 0 dB No Fan
Electrical characteristics
Maximum heat dissipation
81 BTU/hr (85 kJ/hr) 61 BTU/hr (64 kJ/hr)
Voltage
100-240 VAC 100-127 / 200-240 VAC
Current
0.7 / 0.4 A 1.0 / 0.8 A
Power consumption
24 W 18 W
Frequency
50 / 60 Hz 50 / 60 Hz
Notes
Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure with fully
loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules
populated.
Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure with fully
loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules
populated.
The exact input voltage and frequency rating are determined by the specific
power adapter part number ordered. Please select the correct power adapter
country option.
Safety
CSA 22.2 No. 60950; EN 60950/IEC 60950; UL 60950 CSA 22.2 No. 60950; EN 60950/IEC 60950; UL 60950
Emissions
FCC Rules Part 15, Subpart B Class A; EN 55022; VCCI; ICES-003 (Canada) FCC Rules Part 15, Subpart B Class A; EN 55022; VCCI; ICES-003 (Canada)
Immunity
EN
EN 55024, CISPR 24 EN 55024, CISPR 24
ESD
IEC 61000-4-2 IEC 61000-4-2
Radiated
IEC 61000-4-3 IEC 61000-4-3
EFT/Burst
IEC 61000-4-4 IEC 61000-4-4
Surge
IEC 61000-4-5 IEC 61000-4-5
Conducted
IEC 61000-4-6 IEC 61000-4-6
Power frequency magnetic field
IEC 61000-4-8 IEC 61000-4-8
Voltage dips and interruptions
IEC 61000-4-11 IEC 61000-4-11
Harmonics
IEC 61000-3-2 IEC 61000-3-2
Flicker
IEC 61000-3-3 IEC 61000-3-3
Notes
Use only supported genuine ProCurve mini-GBICs with your switch.
