2-11
Installing the Switch 2124
Installation Procedures
Installing the Switch 2124
2. Attach the switch to the wall or wood surface with 5/8-inch number 12
wood screws (not included).
5/8-inch
wood screws
5/8-inch
wood screw
second 5/8-inch
wood screw (hidden)
For “Bookshelf” Wall Mounting For “Flat” Wall Mounting
