3. Release the slot cover retention latch that secures the slot covers by lifting the tab on the latch and
rotating the latch to the open position.
4. Locate the correct vacant expansion socket on the system board and the corresponding expansion slot
on the back of the computer chassis.
5. Before installing an expansion card, remove the expansion slot cover or the existing expansion card.
NOTE: Before removing an installed expansion card, disconnect any cables that may be attached to
the expansion card.
a. If you are installing an expansion card in a vacant socket, you must slide one of the expansion slot
covers up and out of the chassis or use a atblade screwdriver to pry out one of the metal shields
on the rear panel that covers the expansion slot. Be sure to remove the appropriate shield for the
expansion card you are installing.
28 Chapter 4 Removal and replacement procedures – Microtower (MT) chassis

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP ProDesk 600 G2 Series and is the answer not in the manual?

HP ProDesk 600 G2 Series Specifications

General IconGeneral
Processor OptionsIntel Core i3, Intel Core i5, Intel Core i7 (6th Gen)
MemoryUp to 64 GB DDR4
Storage OptionsHDD, SSD
GraphicsIntel HD Graphics, Optional discrete graphics
PortsUSB 3.0, USB 2.0, DisplayPort, VGA, RJ-45
Form FactorSmall Form Factor (SFF), Mini Tower (MT)
Operating SystemWindows 10 Pro, Windows 7 Professional
Expansion SlotsPCIe x16, PCIe x1, PCI
Power Supply200W
DimensionsVaries by form factor
WeightVaries by form factor
