Power supply
Description
Power supply, 280W, 92% ecient
Power supply, 280W, 85% ecient
Power supply, 280W, standard
1. Prepare the computer for disassembly (Preparation for disassembly on page 19).
2. Remove the access panel (Access panel on page 20).
3. Remove the four silver Torx T15 screws that connect the power supply to the rear of the chassis.
4. Remove the power cable from the clip on the base pan.
Power supply 49
