XU1 Black Processor FRONT USB Yellow Front I/O
CPUFAN White Processor fan SATA2 Light blue Any SATA Device other
than the primary hard
drive
DIMM4 White Memory module PSWD Green Clear system passwords
DIMM3 Black Memory module CMOS Yellow Reset CMOS
DIMM2 White Memory module BATTERY Black RTC battery
DIMM1 Black Memory module HSENSE White Hood sensor
PB/LED Black Front I/O/power switch FRONT AUD Blue Front I/O
System board 53
