HP ProDesk 600 G3 Small Form Factor Business

EL-MF877-00 Page 11
Template Revision B
PSG instructions for this template are available at EL-MF877-01

9
Release 4 screws
from cooler then
unplug cable as
shown.
See Photo 23, 24
Screw tool:
Star screwdriver OD
3.3mm.
Photo 24
Photo 23
