HP ProDesk 600 G3 Small Form Factor Business

EL-MF877-00 Page 19
Template Revision B
PSG instructions for this template are available at EL-MF877-01

20
Release 4 screws as
shown.
Push PSU latch then pull
PSU then pick up PSU
from chassis as shown.
See Photo 48, 49, 50
Screw tool:
Star screwdriver OD
3.3mm.
21
Release one screw then
pick up speaker from
chassis as shown.
See Photos 51, 52
Screw tool:
Cross screwdriver OD
3.0mm.
Photo 48
Photo 50
Photo 49
Push
1
2
Photo 51
Photo 22
