HP ProDesk 600 G3 Small Form Factor Business

EL-MF877-00 Page 16
Template Revision B
PSG instructions for this template are available at EL-MF877-01

16
Release two screws
then pull up option
card as shown.
See Photo 37, 38
Screw tool:
Cross screwdriver
OD 3.0mm.
17
Release one screw
then pull up card
reader as shown.
See Photo 39, 40
Screw tool:
Star screwdriver OD
3.3mm.
Photo 37
Photo 38
1
2
Photo 39
Photo 40
1
2
