Drive bay configuration
The server supports a maximum of five drive bays – four bays for 3.5-inch hard disk drives and one
drive bay for an optical media drive.
Figure 14 System drive bays
Item Description
1 Optical Media Device Bay
2 3.5 Inch Hard Disk Drive Bays (four)
The HDD bays support both non-hot-plug and hot-plug SATA drives, as well as hot-plug SAS drives.
