Diagnostic tools and setup utilities 142
Advanced menu
Figure 125 Advanced Menu of the BIOS Setup Utility
ROM-based Setup Utility
Main <Advanced> Boot Security Exit
Advanced Settings
Custom: Allow to
configure Efficiency
/Performance related
items individually.
Efficiency
/Performance: Impact
groups as CPU
Configuration/CPU
bridge Configuration
WARNING: Setting wrong values in below sections
may cause system to malfunction.
Power Efficiency Mode [Efficiency]
Power Supply Redundancy Mode [High Efficiency]
> CPU Configuration
> CPU Bridge Configuration
> SATA Configuration
> SuperIO Configuration /PCI Express
Configuration
←→ Select Screen
↑↓ Select Item
Enter Go to Sub Screen
F1 General Help
> USB Configuration
> PCI Configuration
> PCI Express Configuration
> IPMI Configuration
> BIOS Serial Console Configuration
> Trusted Computing
Intel VT-d Configuration
F10 Save and Exit
ESC Exit
V02. 61(C) Copyright 1985-2006, American Megatrends, Inc.
WARNING: Incorrect settings may cause the server to malfunction. To correct the settings, press the
F9 key to restore the default settings.
• CPU Configuration—Configure CPU settings.
• CPU Bridge Configuration—Configure CPU bridge settings.
• SATA Configuration—Configure SATA settings.
• SuperIO Configuration—Configure Super I/O settings.
• USB Configuration—Configure USB settings.
• PCI Configuration—Configure PCI settings.
• PCI-Express Configuration—Configure PCI Express settings.
• IPMI Configuration—Configure the IPMI settings.
• BIOS Serial Console Configuration—Configure the BIOS Serial Console settings.
