Note:
In addition to the indicators listed above see also UG: Rear panel LEDs and buttons.
Troubleshooting external server components
Use the checklist below to troubleshoot any of the following external server components:
Part number Description Hot-swappable?
700501426 DL360G7 SRVR 146GB 10K SAS 2.5”
HDD
Y
700501249 DL360G7 SRVR 146GB 15K SAS 2.5”
HDD
Y
700501314 DL360G7 SRVR 300GB 10K SAS 2.5”
HDD
Y
700501182 DL360G7 SRVR PWR SUP 460W HE Y, if redundant
700501312 DL360G7 SRVR AC PWR SUP 750W Y, if redundant
700501313 DL360G7 SRVR DC PWR SUP 1200W Y, if redundant
No. Task Reference Avaya
recommendation
1 Visually check for
hardware LED fault
indicators:
• DL360G7 SRVR
146GB 10K SAS 2.5”
HDD
• DL360G7 SRVR
146GB 15K SAS 2.5”
HDD
• DL360G7 SRVR
300GB 10K SAS 2.5”
HDD
MSG: SAS and SATA
hard drive LEDs
TG: Hard drive LED
combinations
If the hardware LED
indicates a problem,
consult the appropriate
troubleshooting
information.
