Diagnostics and Troubleshooting
Compaq ProLiant DL360 Server Maintenance and Service Guide 4-47
COMPAQ CONFIDENTIAL Codename: MIcroMachines Part Number: 169616-006 Last Saved On: 12/21/01 9:05 AM
Table 4-16: ADU Diagnostic Messages continued
Message Description Recommended Action
Logical
Drive X status
= WRONG
DRIVE
REPLACED
A physical drive in this logical drive
has failed. The incorrect drive was
replaced.
Replace the drive that was incorrectly
replaced. Then, replace the original drive
that failed with a new drive. Do not run the
System Configuration Utility to
reconfigure; data on drive will be lost.
Loose cable
detected -
logical drives
may be
marked
FAILED until
corrected
ADU found loose cable. If logical
drives are marked FAILED, those
logical drives will be unusable until
problem corrected.
Controller unable to communicate
with one or more physical drives,
probably because of a cabling
problem. Logical drives may be in a
FAILED state until the condition is
corrected, preventing access to
data on the controller.
Turn off the system. Check cable(s) for
tight connection to logical drives. Restart
system. If same message recurs, cable(s)
may be bad.
Check all controller and drive cable
connections.
Mirror data
miscompared
Data was found at reinitialization in
the posted write memory; however,
the mirror data compare test failed
resulting in data being marked as
invalid. Data loss is possible.
Replace the array accelerator board.
No
configuration
for accelerator
board
The array accelerator board has not
been configured.
If the array accelerator board is present,
run the Array Configuration Utility (ACU) to
configure the board.
NVRAM
configuration
present,
controller not
detected
Nonvolatile RAM has a
configuration for an array controller,
but there is no board in this slot.
Either a board has been removed
from the system or a board has
been placed in the wrong slot.
Place the array controller in the proper slot
or run the System Configuration Utility to
reconfigure nonvolatile RAM to reflect the
removal or new position.
RIS copies
between
drives do not
match
Drives on controller contain copies
of RIS that do not match.
Upgrade ADU to the most recent version.
SCSI Port x
Drive ID x has
exceeded
threshold(s)
Monitor and performance threshold
for this drive has been violated.
Check for the particular threshold that has
been violated.
SCSI Port x
Drive ID x is
not stamped
for monitoring
Drive has not been stamped with
monitor and performance features.
Run the Array Configuration Utility (ACU).
Changing the configuration and saving
should cause ACU to stamp drive with
monitor and performance features. To do
this without destroying the current
configuration, change array accelerator
size and save configuration. Change the
array accelerator back to original size and
save again.
continued
