HP ProLiant DL385p Gen8 - System Maintenance Switch

Component identification 16
Item Description
11
Processor 2 DIMM slots
12
Second drive cage
13
Fan connector 1
14
NMI jumper
15
Front video connector
16
Discovery services connector
17
System maintenance switch
18
SATA optical drive connector
19
SATA drive port 1
20
Power supply backplane connector
21
USB connector
22
SD card slot
23
Secondary (processor 2) PCIe riser connector
24
Processor 2 socket
25
System battery
26
TPM connector
27
Primary (processor 1) PCIe riser connector
28
Processor 1 socket
29
FlexibleLOM
30
SAS port 1i
31
SAS port 2i
32
SAS cache module connector
System maintenance switch
Position Default Function
S1
Off Off = HP iLO security is enabled.
On = HP iLO security is disabled.
S2
Off Off = System configuration can be
changed.
On = System configuration is locked.
S3
Off Reserved
S4
Off Reserved
S5
Off
Off = Power-on password is enabled.
On = Power-on password is disabled.
S6
Off Off = No function
On = ROM reads system configuration
as invalid.
S7
— Reserved
S8
— Reserved
S9
— Reserved
S10
— Reserved
S11
— Reserved
S12
— Reserved
