HP ProLiant ML310e Specification

HP iLO Advanced including 1yr 24x7 Technical Support and Updates Tracking License 512487-B21
NOTE: For additional license kits, including electronic delivery options, please see the
QuickSpecs at:
http://h18004.www1.hp.com/products/quickspecs/14276_div/14276_div.html
NOTE: For more information, visit: http://www.hp.com/go/ilo .
HP Security HP Trusted Platform Module Option 488069-B21
NOTE: The TPM (Trusted Platform Module) is a microcontroller chip that can securely
store artifacts used to authenticate the server platform. These artifacts can include
passwords, certificates and encryption keys. Windows® BitLocker™ Drive Encryption
(BitLocker) is a data protection feature available in Windows Server® 2008. BitLocker
leverages the enhanced security capabilities of a Trusted Platform Module (TPM)
version 1.2. The TPM works with BitLocker to help protect user data and to ensure that
a server running Windows Server 2008 has not been tampered with while the system
was offline. For more information about TPM, including a white paper, go to:
www.hp.com/go/TPM .
NOTE: ProLiant OS pre-installed units will come with the partition required for TPM
deployment.
NOTE: The TPM key is unique to every TPM deployed server and must be retained.
Misplacing or losing the key could result in data loss.
HP Storage Controllers SAS Controllers
NOTE: Smart Array Storage controller can be added only in PCIe Slot 3, Slot 4 or both.
HP Smart Array P222 Controller
HP Smart Array P222/512 FBWC 6Gb 1-port Int/1-port Ext SAS Controller 631667-B21
HP Smart Array P420 Controller
HP Smart Array P420/2GB FBWC 6Gb 2-ports Int SAS Controller 631671-B21
HP Smart Array P420/1GB FBWC 6Gb 2-ports Int SAS Controller 631670-B21
HP Smart Array P421 Controller
HP Smart Array P421/2GB FBWC 6Gb 2-ports Ext SAS Controller 631674-B21
HP Smart Array P421/1GB FBWC 6Gb 2-ports Ext SAS Controller 631673-B21
Optional Upgrades
HP 2GB P-series Smart Array Flash Backed Write Cache 631681-B21
HP SmartCache No Media 24x7 Technical Support 1 Svr License D7S26A
HP SmartCache No Media 24x7 Technical Support Flexible License D7S27A
HP SmartCache No Media 24x7 Technical Support Electronic License D7S27AAE
NOTE: Please see the QuickSpecs for Technical Specifications and additional
information:
http://h18000.www1.hp.com/products/quickspecs/14227_div/14227_div.html
(Smart Array P222 Controller)
http://h18000.www1.hp.com/products/quickspecs/14228_div/14228_div.html
(Smart Array P420 Controller)
http://h18000.www1.hp.com/products/quickspecs/14229_div/14229_div.html
(Smart Array P421 Controller)
QuickSpecs
HP ProLiant ML310e Generation 8 (Gen8) v2
Additional Options
DA - 14564 Worldwide — Version 11 — December 13, 2013 Page 26

HP ProLiant ML310e Specifications

General

Bus type	DMI
Stepping	C0
FSB Parity	No
Scalability	1S
Processor cache	8 MB
Processor cores	4
Processor model	E3-1220V3
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200 v3
Processor socket	LGA 1150 (Socket H3)
Processor codename	Haswell
Motherboard chipset	Intel® C222
Processor frequency	3.1 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	- MHz
Processor boost frequency	3.5 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x8, 1x16, 2x4, 2x8
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)	80 W
Number of processors installed	1
Thermal solution specification	PCG 2013D
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	32 GB
HDD size	3.5 \
HDD speed	7200 RPM
RAID levels	0, 1, 10
HDD interface	Serial ATA III
Optical drive type	DVD-RW
Total storage capacity	1000 GB
Maximum storage capacity	16 TB
Supported storage drive interfaces	SAS, Serial ATA
Internal memory	4 GB
Memory clock speed	1333 MHz
Memory layout (slots x size)	1 x 4 GB
Maximum graphics card memory	16 MB
On-board graphics card model	Not available
Graphics card	G200
Graphics card family	Matrox
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
PCI Express slots version	3.0
Operating system installed	-
Compatible operating systems	Windows Server\\r Ubuntu\\r Red Hat Enterprise Linux\\r SUSE Linux Enterprise Server\\r VMware
Noise level	26 dB
Chassis type	Tower (4U)
Power supply	350 W
Power supply input frequency	47/63 Hz
Certification	FCC; CISPR 22; EN55022; EN55024; FCC CFR 47; ICES-003; CNS13438; GB9254; K22; K24; EN 61000-3-2; EN 61000-3-3; EN 60950-1; IEC 60950-1
Processor ARK ID	75052
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	475.2 mm
Width	175 mm
Height	368.2 mm
Weight	18960 g
