NOTE:
The Service Pack for ProLiant (which includes HP SUM) can be
downloaded from
www.hp.com/go/spp/download
. More information can be
found:
http://www.hp.com/go/SmartUpdate
,
www.hp.com/go/spp
and
http://www.hp.com/go/hpsum
Security
Power-on password
Administrator's password
Warranty
This product is covered by a global limited warranty and supported by HP Services and a worldwide
network of HP Authorized Channel Partners resellers. Hardware diagnostic support and repair is available
for three years from date of purchase. Support for software and initial setup is available for 90 days from
date of purchase. Enhancements to warranty services are available through HP Care Pack services or
customized service agreements. Hard drives have either a one year or three year warranty; refer to the
specific hard drive QuickSpecs for details.
NOTE:
Server Warranty includes 1-Year Parts, 1-Year Labor, 1-Year Onsite support with next business day
response. (3-1-1 warranty offered in Brazil only). Warranty repairs may be accomplished through the use
of Customer Self Repair (CSR) parts. These parts fall into two categories: 1) Mandatory CSR parts are
designed for easy replacement. A travel and labor charge will result when customers decline to replace a
Mandatory CSR part; 2) Optional CSR parts are also designed for easy replacement but may involve added
complexity. Customers may choose to have HP replace Optional CSR parts at no charge. Additional
information regarding worldwide limited warranty and technical support is available at:
http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html
QuickSpecs
HP ProLiant ML310e Generation 8 (Gen8) v2
Standard Features
DA - 14564 Worldwide — Version 11 — December 13, 2013
Page 9

Other manuals for HP ProLiant ML310e

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP ProLiant ML310e and is the answer not in the manual?

HP ProLiant ML310e Specifications

General IconGeneral
Bus typeDMI
SteppingC0
FSB ParityNo
Scalability1S
Processor cache8 MB
Processor cores4
Processor modelE3-1220V3
System bus rate5 GT/s
Processor seriesIntel Xeon E3-1200 v3
Processor socketLGA 1150 (Socket H3)
Processor codenameHaswell
Motherboard chipsetIntel® C222
Processor frequency3.1 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor package size37.5 x 37.5 mm
Processor front side bus- MHz
Processor boost frequency3.5 GHz
Processor operating modes64-bit
ECC supported by processorYes
PCI Express configurations1x8, 1x16, 2x4, 2x8
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)80 W
Number of processors installed1
Thermal solution specificationPCG 2013D
Maximum number of PCI Express lanes16
Memory types supported by processorDDR3-SDRAM
Memory channels supported by processorDual
Memory clock speeds supported by processor1333, 1600 MHz
Memory bandwidth supported by processor (max)25.6 GB/s
Maximum internal memory supported by processor32 GB
HDD size3.5 \
HDD speed7200 RPM
RAID levels0, 1, 10
HDD interfaceSerial ATA III
Optical drive typeDVD-RW
Total storage capacity1000 GB
Maximum storage capacity16 TB
Supported storage drive interfacesSAS, Serial ATA
Internal memory4 GB
Memory clock speed1333 MHz
Memory layout (slots x size)1 x 4 GB
Maximum graphics card memory16 MB
On-board graphics card modelNot available
Graphics cardG200
Graphics card familyMatrox
Intel® Virtualization Technology (Intel® VT)VT-d, VT-x
Cabling technology10/100/1000Base-T(X)
Ethernet interface typeGigabit Ethernet
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
PCI Express slots version3.0
Operating system installed-
Compatible operating systemsWindows Server\\r Ubuntu\\r Red Hat Enterprise Linux\\r SUSE Linux Enterprise Server\\r VMware
Noise level26 dB
Chassis typeTower (4U)
Power supply350 W
Power supply input frequency47/63 Hz
CertificationFCC; CISPR 22; EN55022; EN55024; FCC CFR 47; ICES-003; CNS13438; GB9254; K22; K24; EN 61000-3-2; EN 61000-3-3; EN 60950-1; IEC 60950-1
Processor ARK ID75052
Intel Identity Protection Technology version1.00
Weight and Dimensions IconWeight and Dimensions
Depth475.2 mm
Width175 mm
Height368.2 mm
Weight18960 g
