Operations 31
Remove the DVD-ROM drive
1. Power down the server (on page 22).
2. Do one of the following:
o Open or remove the tower bezel, as needed ("Open or remove the tower bezel" on page 22).
o Extend the server from the rack (on page 24).
3. Remove the access panel (on page 25).
4. Remove fan 5 (on page 26).
5. If installed, remove the BBWC battery pack or the FBWC capacitor pack (on page 27).
6. Remove the air baffle (on page 28).
7. Remove the fan cage (on page 29).
8. Disconnect and remove the DVD-ROM drive data/power cable. For more information, see "DVD-ROM
drive cabling (on page 110)."
9. Remove the DVD-ROM drive.
Remove the hard drive cage blank
1. Power down the server (on page 22).
2. Do one of the following:
o Open or remove the tower bezel, as needed ("Open or remove the tower bezel" on page 22).
o Extend the server from the rack (on page 24).
