Attaching the computer to a mounting fixture
The computer stand is secured to a VESA mount inside the computer chassis. You can remove the
stand and install the computer on a wall, monitor arm, or other mounting fixture.
Table 3-1 Computer dimensions (without stand)
Computer dimensions (without stand)
Height 362.9 mm 14.3 in
Width 557.9 mm 22.0 in
Depth 59.4 mm 2.3 in
Computer weight (without stand)
Minimum configuration 7.42 kg 16.4 lb
With Options 7.57 kg 16.7 lb
VESA standard hole patterns
height x width 100 mm x 100 mm 3.94 in x 3.94 in
To remove the stand:
1. Remove all removable media, such as optical discs or USB flash drives, from the computer.
2. Turn off the computer properly through the operating system, then turn off any external devices.
3. Disconnect the power cord from the power outlet and disconnect any external devices.
CAUTION: Regardless of the power-on state, voltage is always present on the system board
as long as the system is plugged into an active AC outlet. You must disconnect the power cord
to avoid damage to the internal components of the computer.
4. Remove/disengage any security devices that prohibit opening the computer.
5. Place the computer face down on a soft flat surface. HP recommends that you set down a
blanket, towel, or other soft cloth to protect the bezel and screen surface from scratches or other
damage.
6. Loosen the two captive screws at the bottom of the computer (1) to release the bottom edge of
the access panel.
Attaching the computer to a mounting fixture 17
