I/O Ports
USB 2.0
Front: Two (2), covered
Rear: Five (5)
USB 24V
One (1) 24V powered USB
Serial
Two (2) RS-232 (power configurable) ports standard
Parallel
One port available as an option
*
eSATA
One port available as an option
*
RS-232
Two (2) RS-232 powered configurable ports optional (for a total of 4*)
USB+PWR 12V
Two (2) USB+PWR 12V cards optional (three (3) 12 Volt USB+ PWR per card) for a total of 6*
PS/2
One (1) color-coded support for keyboard (purple)
One (1) color-coded support for mouse (green)
RJ-11
One (1) RJ-11 Cash Drawer port
Video
One (1) VGA
One (1) DisplayPort v1.1a
Provides integrated dual independent monitor support
DVI output
Available via optional DisplayPort to DVI Adapter
Audio
Rear: Line input (supports microphone or line input) and line out
All ports are 3.5mm in diameter
NOTE:
See Audio/Visual section for information on re-taskable audio ports
NIC
One (1) Industry standard RJ-45 port accesses the integrated network interface controller
*These options occupy slot openings so less slots will be available when the options are installed
Serial Ports (Power Configurable in HP Bios) – detail
1 and 2:
Powered Configurable serial port expansion card installation that supplies two additional serial ports (COM3 and COM4)
3 and 4:
Two Power Configurable serial ports, COM1 and COM 2, are standard on the POS System.
QuickSpecs
HP rp5800 Retail System
Standard Features and Configurable Components (availability may vary by country)
DA - 13982 North America — Version 12 — November 8, 2013
Page 10
