DDR3 Synchronous DRAM NON-ECC System Memory
Memory upgrades are accomplished by adding single or multiple DIMMs of the same or varied sizes. This chart does not represent
all possible memory configurations. The HP rp5800 Retail System supports non-ECC DDR3 PC3-12800 (1600 MHz) and PC3-
10600 (1333 MHz) memory.
CAUTION:
You must shut down the Retail System and disconnect the power cord before adding or removing memory modules.
Regardless of the power-on state, voltage is always supplied to the memory modules as long as the Retail System is plugged in to
an active AC outlet. Adding or removing memory modules while voltage is present may cause irreparable damage to the memory
modules or system board.
Memory Configurations:
Maximum Memory
Supports up to 16 GB of DDR3 SDRAM using DIMM modules. Slot 1 is black and must always
be populated. Not all memory configurations possible are represented below.
NOTE:
For systems configured with more than 3 GB of memory and a 32-bit operating system, all
memory may not be available due to system resource requirements. Addressing memory
above 4 GB requires a 64-bit operating system.
Total Memory
Slot
Channel A
Channel B
1 (black)
2 (white) 3 (white) 4 (white)
1 GB 1 GB
2 GB
(dual channel symmetric)
1 GB
1 GB
4 GB
(dual channel symmetric)
1 GB 1 GB 1 GB 1 GB
8 GB
(dual channel symmetric)
2 GB 2 GB 2 GB 2 GB
16 GB
(dual channel symmetric)
4 GB 4 GB 4 GB 4 GB
NOTE:
The Intel Q67 Express chipset includes a built-in Management Engine (ME), which allocates memory for manageability
functions. Management Engine memory is shared with system memory. If the POS System contains a single SO-DIMM, 16 MB of
memory is pre-allocated for it at system startup. If the POS System contains two SO-DIMMs, 32 MB of memory is pre-allocated. This
memory is not made available to the operating system, just as pre-allocated video memory is not available.
QuickSpecs
HP rp5800 Retail System
Standard Features and Configurable Components (availability may vary by country)
DA - 13982 North America — Version 12 — November 8, 2013
Page 7
