Operating Temperature
(System Inlet Air
Temperature)
50° to 95° F (10° to 35° C)
NOTE:
To support HP hard drives exceeding 2.2 TB, HP Smart Array Firmware
version 5.0 or later is required for the following controllers:
HP Smart Array P212 Controller
HP Smart Array P410 Controller
HP Smart Array P411 Controller
HP Smart Array P711m Controller
HP Smart Array P812 Controller
To use hard drives exceeding 2.2 TB, you must create a boot volume using
offline ACU version 8.75 or later. HP Smart Array controllers do not support
boot volumes exceeding 2.2 TB. Other controllers are not supported
HP 3TB 6G SAS 7.2K rpm
LFF (3.5-inch) SC Midline
1yr Warranty Hard Drive
652766-B21
Capacity
3,000,592MB
Height
1.06 in (26.8 mm)
Width
4.16 in (105.8 mm)
Depth
6.69 in (170.0 mm)
Interface
SAS
Transfer Rate
Synchronous
(Maximum)
6 Gb/sec
Seek Time
(typical reads, including
settling)
Single Track
0.7 ms
Average
8.3 ms
Full-Stroke
15.7 ms
Rotational Speed
7200 rpm
Physical Configuration
Bytes/Sector
512
Logical Blocks
5,860,533,168
Operating Temperature
(System Inlet Air
Temperature)
50° to 95° F (10° to 35° C)
NOTE:
To support HP hard drives exceeding 2.2 TB, HP Smart Array Firmware
version 5.0 or later is required for the following controllers:
HP Smart Array P212 Controller
HP Smart Array P410 Controller
HP Smart Array P411 Controller
HP Smart Array P711m Controller
HP Smart Array P812 Controller
To use hard drives exceeding 2.2 TB, you must create a boot volume using
offline ACU version 8.75 or later. HP Smart Array controllers do not support
boot volumes exceeding 2.2 TB. Other controllers are not supported
QuickSpecs
HP SAS Hard Drives
Technical Specifications
DA - 12244 North America — Version 44 — December 9, 2013
Page 15
