Solid-state drive
Description Spare part number
128-GB mSATA solid-state drive (SSD) 689953-001
256-GB mSATA solid-state drive (SSD) 689955-001
Before removing the SSD, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the base enclosure (see
Base enclosure on page 27).
5. Disconnect the battery cable (see
Battery on page 29).
Remove the solid-state drive:
1. Remove the 2 Phillips PM 2.0x2.0 screws (1) securing the solid–state drive to the top cover. The
drive tilts upwards.
2. Remove the solid–state drive (2).
Reverse these procedures to reassemble and install the hard drive.
Component replacement procedures 33
