4. Remove the keyboard bracket (1). Make sure the keyboard cables are disengaged from the
bracket as you remove the keyboard bracket (2). Make sure to push the keyboard cables
through the bracket.
5. Remove the 3 black Phillips PM 2x2 screws (1), and then remove the 3 Phillips PM 1.6 screws
(2).
6. Remove the keyboard (3).
Reverse this procedure to install the keyboard.
WLAN antenna cables
Description Spare part numbers
WLAN antennas 670292-005
Before removing the antenna cables:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
58 Chapter 4 Removal and replacement procedures
