16. Disconnect the cable from the webcam (3).
Reverse this procedure to install the display panel.
Webcam assembly
Description Spare part numbers
Webcam assembly 689965-001
Before removing the webcam assembly:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the display panel (see
Display panel on page 51).
5. Remove the base enclosure (see
Base enclosure on page 27).
6. Disconnect the battery cable (see
Battery on page 29).
Remove the webcam assembly:
Component replacement procedures 55
